Schneider Electric LRD21 | TeSys LRD Thermal Overload Relay 12-18A Class 10A
Schneider Electric LRD21 (TeSys LRD) thermal overload relay. 12-18A adjustable range, Class 10A trip, 690V AC, 1NO+1NC contacts. For motor protection with LC1D contactors.
Product Overview
The Schneider Electric LRD21 is a thermal overload relay from the TeSys LRD series (also known as TeSys Deca). It provides motor protection (overload, phase unbalance) for 3-phase AC motors in the 12–18 A full load current range. Designed for direct mounting under TeSys D contactors (e.g., LC1D18 to LC1D38), it features ambient temperature compensation, manual reset, and a compact form factor for industrial control panels.
Technical Specifications (Electrical & Protection)
| Parameter | Specification |
| Manufacturer / Series | Schneider Electric / TeSys LRD (Deca) |
| Model / Part Number | LRD21 |
| Product Type | Thermal Overload Relay (Differential, Bi-metallic) |
| Rated Operational Voltage (Ue) | 690 V AC (50/60 Hz, 0–400 Hz range) |
| Current Setting Range (Ir) | 12 – 18 A (Adjustable via dial) |
| Trip Class | Class 10A (per IEC 60947-4-1) |
| Phase Failure Sensitivity | Trips at ~130% Ir on two phases |
| Auxiliary Contacts | 1 NO + 1 NC (Signaling Circuit) |
| Control Circuit Rating | 1.5 A at 240V AC-15; 0.1 A at 250V DC-13 |
Technical Specifications (Mechanical & Environmental)
| Parameter | Specification |
| Compatible Contactors | LC1D18, LC1D25, LC1D32, LC1D38 (TeSys D) |
| Mounting | Direct under contactor, DIN rail, or plate |
| Connection Type | Screw Clamp Terminals |
| Terminal Wire Range | Power: 1.5–10 mm²; Control: 1–2.5 mm² |
| Dimensions (W×H×D) | 45 × 66 × 70 mm |
| IP Rating | IP20 |
| Operating Temperature | -20 °C to +60 °C (with compensation) |
| Reset Type | Manual (Blue push-button), Red stop button |
Key Features
-
Class 10A Tripping: Fast response (≈10 seconds) at 7.2× Ir for motor stall protection.
-
Ambient Compensation: Maintains trip accuracy across -20°C to +60°C environments.
-
Visual Trip Indication: Clear flag/button indication for quick fault diagnosis.
-
Screw Clamp Reliability: Robust terminals for power and control wiring.
Applications
-
Protection of 3-phase AC motors (pumps, fans, conveyors)
-
Industrial machine control panels
-
Motor starter combinations with TeSys D contactors
