Pepperl+Fuchs NBN3-F31K-Z8-K | M8 3mm Sensor, 2 NO, IP67
Pepperl+Fuchs NBN3-F31K-Z8-K inductive proximity sensor. M8 threaded barrel, 3mm range, 2 normally open outputs, 6-60V DC, IP67, -25°C to +70°C.
Product Overview
The Pepperl+Fuchs NBN3-F31K-Z8-K is a compact M8 inductive proximity sensor designed for space-constrained industrial applications. It features a 3 mm sensing range for detecting metallic objects and offers dual normally open (NO) outputs for flexible wiring configurations. With a wide 6-60V DC operating voltage and IP67 protection rating, this sensor is suitable for use in harsh environments where reliable object detection is critical.
Technical Specifications (Electrical & Functional)
| Parameter | Specification |
| Sensor Type | Inductive Proximity (Shielded / Flush Mount) |
| Output Type | 2 Normally Open (NO) Contacts |
| Rated Operating Distance | 3 mm |
| Assured Operating Distance | 0 ... 2.43 mm |
| Operating Voltage | 6 ... 60 V DC |
| Switching Frequency | 0 ... 500 Hz |
| Voltage Drop | ≤ 5.5 V |
| Switching Current | 4 ... 100 mA |
| Hysteresis | Typ. 5% |
| Protection | Reverse Polarity, Short-circuit (Pulsing) |
Technical Specifications (Mechanical & Environmental)
| Parameter | Specification |
| Housing | PBT Plastic |
| Thread Size | M8 x 1 |
| Connection | Cage Clamp Terminal |
| Wire Cross-Section | 1.5 / 2.5 mm² |
| Degree of Protection | IP67 |
| Operating Temperature | -25 °C ... +70 °C |
| Housing Length | 31 mm |
| Weight | Approx. 18 g |
| Mounting | Flush Mountable |
Key Features
-
Dual Output Configuration: Features two independent normally open (NO) contacts, providing wiring flexibility for control circuits.
-
Wide Voltage Range: Operates on 6-60V DC, making it compatible with a variety of industrial control systems.
-
Compact Design: M8 threaded barrel allows for easy installation in tight spaces where larger sensors cannot fit.
Applications
-
Position detection of small metal parts on conveyor systems
-
End-of-stroke sensing in compact pneumatic cylinders
-
Presence verification in assembly automation and packaging machinery
